Our small diameter welded and cold-reduced tubes deliver a harmonious blend of strength and quality across an extensive range of sizes.
Leader in Speciality Tubes
ISO 9001:2015 & IATF 16949:2016 Certified Organization
Gandhi Special Tubes manufactures Precision Electric Resistance Welded Tubes for heating elements, fuel lines, evaporative coils, and general engineering applications.
Trusted across industries that demand strength, precision, and reliability.
Precision welded tubes formed for reliable heating element assemblies.
Electric-resistance welded tubes engineered for reliable fuel delivery.
Formable welded tubing suited to refrigeration and evaporative coil manufacturing.
Versatile precision welded tubes suited to a wide range of engineering applications.
Why choose our welded tubes
Our small diameter welded and cold-reduced tubes deliver a harmonious blend of strength and quality across an extensive range of sizes.
The journey begins with low carbon steel CRCA coils meticulously sourced from prime steel plants globally.
We utilize advanced German technology to manufacture our precision welded steel tubes.
The process involves Continuous Forming, Direct Current Welding, and Sizing by passing through a set of stretch reducing rolls.
Strict process controls ensure that the internal weld bead is held to a minimum, and any external ¬ashing is meticulously removed.
Our tubes undergo bright annealing in an advanced German continuous Roller Hearth Furnace, resulting in a product that is soft, scale-free, and radiantly bright, boasting excellent physical properties.
To ensure robust quality, each tube undergoes rigorous pressure testing at up to 70 Kg/cm sq pressure with dry nitrogen under water.
Our tubes can be supplied in Plain, Copper Coated, or Electrogalvanized conditions.
Product dimensions
At Gandhi Special Tubes Ltd, tubes and nuts are supplied in accordance with appropriate International Standards in a large variety of steel grades and dimensions. Client specific requirements on technical parameters are offered on request.
Technical guidance
Electric-resistance-welded (ERW) tubes are made by roll-forming steel strip into a tube, fusing the seam with electric current and sizing it to precise dimensions. Gandhi's precision ERW tubes are small-diameter, cold-reduced tubes offering accurate dimensions and cost-effective performance for fluid lines and general engineering.
Our welding process involves continuous forming, DC resistance welding & sizing by passing through a set of stretch reducing rolls. Strict process controls ensure that the internal weld bead is held to a minimum, and any external flashing is meticulously removed.
The choice between welded and seamless tubes depends on the application and performance requirements. Seamless tubes are preferred for demanding pressure and fatigue applications. Welded tubes can offer a cost-effective solution where appropriate.
Gandhi's precision welded tubes are supplied to standards such as DIN 2393, DIN 2394, EN 10305-3, SAE J526, SAE J356 (or equivalent), IS 3074 and JIS G 3445, according to the application and grade. The governing standard, agreed at enquiry, sets the dimensions, tolerances and test requirements for your order.
Yes - small-diameter welded tubes are widely used for low- and medium-pressure fuel feed and return lines, brake and vacuum lines and similar fluid circuits. For high-pressure diesel injection between the pump and injector, use our dedicated high-pressure fuel-injection tubes instead.
To ensure robust quality, each tube undergoes rigorous pressure testing at up to 70 kg/cm² pressure with dry nitrogen under water. Beyond this, welded tubes can undergo eddy-current testing for weld integrity, flattening and flaring tests, plus bending, tensile, hardness, dimensional and surface checks, as required by the ordered standard and customer specification. The test plan is confirmed against your drawing.
Yes. Precision welded tubes are manufactured under Gandhi's ISO 9001:2015 and IATF 16949:2016 certified quality system, which is built for automotive and commercial-vehicle supply. Combined with documented process controls and testing, this supports their use in fuel lines, heating elements and other OEM assemblies. Share your customer standard and any PPAP or documentation requirement at the enquiry stage.
Our continuous manufacturing process enables us to supply tubes in straight lengths or coils, reaching lengths of up to 700 meters.
We can supply tubes in plain, copper coated or electrogalvanized conditions.
Please share the outside diameter, wall thickness and length, the grade or standard, quantity and any drawing/special requirements.
